Eaton 10250TPP2 Pilot Light Lens 30.5mm

Product Description

The EATON 10250TPP2 is a standard-type pilot light lens designed for 30.5mm pushbutton and indicator light assemblies. This small-format lens fits into the 10250T series operator interface hardware and provides a clear or colored light-diffusing surface for panel-mount indicator lights and illuminated pushbuttons. Electricians and panel builders install this lens during new construction or as a direct replacement when an existing lens cracks or discolors. At 0.010 pounds, the lens is a low-mass component that installs without tools beyond what is already needed for the enclosure.

This lens is suited for use in industrial control panels, machine operator stations, and electrical enclosures where 30.5mm pilot light or pushbutton assemblies are installed. It is appropriate for both new panel builds and field replacements. The compact profile, measuring 1.7 inches by 1.7 inches by 0.1 inches, allows it to fit flush within standard 30.5mm cutout assemblies commonly found in commercial and industrial applications.

Key Features

• Standard-type lens for 30.5mm pilot light and pushbutton assemblies
• Low-profile design at 0.1 inches depth
• Lightweight at 0.010 pounds for easy handling during panel work
• Designed for the EATON 10250T series operator interface platform
• Direct drop-in replacement for damaged or discolored lenses

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and illuminated pushbutton assemblies.

Installation Notes

Installation is performed by qualified electricians during panel assembly or maintenance. De-energize the control panel and follow applicable NFPA 70E arc flash and lockout/tagout procedures before servicing any operator interface components. The lens typically snaps or threads into the operator body without special tools. Inspect the lens retainer and operator body for wear before reinstalling.

Technical Specifications

• Series: 10250T Standard Type
• Lens Diameter: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211336026

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TPP2
