Eaton 10250TM87 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM87 is a standard-type pilot light lens designed for use with 30.5mm pilot light and pushbutton assemblies commonly found in industrial control panels and machinery. This lens serves as the protective and color-identifying face component for the pilot light unit, transmitting illumination from the lamp module to the operator. Licensed electricians and industrial control panel builders typically specify this lens when replacing damaged, discolored, or missing lens components on existing operator interface devices. It is a compact, low-profile part suited for panel cutout installations meeting 30.5mm mounting standards.

This lens is appropriate for use in industrial control panel environments, machine operator stations, and motor control centers where 30.5mm pilot light assemblies are installed. It fits into the 10250T series operator device family and is used in both new panel builds and field service replacement applications. Electricians and panel shop technicians working on manufacturing, process control, and automation equipment will encounter this type of lens regularly during maintenance cycles.

Key Features

• Standard-type lens form factor for 30.5mm pilot light assemblies
• Compact dimensions supporting flush or projected lens configurations
• Compatible with 10250T series pilot light and operator device bodies
• Lightweight construction at 0.01 pounds for easy field handling

Compatibility

Designed as an OEM-style replacement lens for 30.5mm pilot light assemblies in the EATON 10250T series operator device family.

Installation Notes

Installation should be performed by a qualified electrician following applicable NEC requirements for control panel work. De-energize the control panel and verify zero voltage at the pilot light circuit before handling any lens or lamp components. The lens typically snaps or threads onto the pilot light body without specialized tools. Inspect the lamp module and socket contacts during lens replacement to confirm proper seating before restoring power.

Technical Specifications

• Mounting Size: 30.5mm
• Length: 5 inches
• Width: 4 inches
• Height: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322458

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM87
