Eaton 10250TM83 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM83 is a standard-type pilot light lens designed for use with 30.5mm push button and operator assemblies. This small-format replacement lens fits into the 10250T series operator housing and provides a clear visual indication window for panel-mounted pilot lights. It is a low-profile component installed by electricians and panel builders during original equipment assembly or field replacement of worn or damaged lens covers. At 0.010 pounds and measuring approximately 1.7 x 1.6 x 0.1 inches, it is a direct-fit part that requires no modification to the host device.

This lens is suited for use in industrial control panels, motor control centers, and machine operator stations where 30.5mm pilot light operators are standard. It is commonly encountered in manufacturing, process control, and commercial electrical applications where panel-mounted indicating lights are used to signal equipment status. Electricians and panel technicians replace these lenses when they become cracked, discolored, or damaged from UV exposure or physical contact during normal service.

Key Features

• Standard-type lens for 30.5mm pilot light operator assemblies
• Low-profile form factor at approximately 0.1 inches thick
• Compact footprint: 1.7 x 1.6 inches for direct housing fit
• Lightweight replacement component at 0.010 pounds
• Part of the EATON 10250T series operator family

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light operator assemblies used in industrial control panel applications.

Installation Notes

Installation is performed by a qualified electrician or panel technician. De-energize the control panel and follow LOTO procedures before removing or replacing any operator lens. The lens typically snaps or threads into the front of the operator body without special tooling. Verify the replacement lens matches the original color and series designation before installation to ensure proper light transmission and panel labeling compliance.

Technical Specifications

• Series: 10250T Standard Type
• Operator Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211320382

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM83
