Eaton 10250TM80 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM80 is a standard-type pilot light lens designed for use with 30.5mm push button and pilot light operator assemblies. This replacement lens fits into the operator housing to protect and diffuse indicator light output, allowing technicians and operators to quickly read control panel status at a glance. It is a commonly replaced component in industrial control panels, machine tool stations, and heavy-duty operator interface enclosures. Electricians and control panel builders working with 30.5mm mounting hardware will find this lens a direct drop-in for worn, cracked, or discolored originals.

This lens is suited for use in industrial and commercial environments where 30.5mm pilot light assemblies are installed in operator stations, control panels, and machine control enclosures. It is appropriate for both new panel builds and field service replacement work. Applications span manufacturing, process control, and utility installations where EATON 10250T-series operator hardware is already in service.

Key Features

• Standard-type 30.5mm lens for pilot light operator assemblies
• Low-profile form factor at 0.1 inches thick
• Compact footprint measuring 1.7 inches by 1.6 inches
• Lightweight at 0.01 pounds for easy handling during panel assembly
• Direct replacement for worn or damaged lenses in existing 10250T-series operators

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T-series 30.5mm pilot light and push button operator assemblies.

Installation Notes

A licensed electrician should perform installation in accordance with applicable NEC requirements. De-energize the control panel and verify absence of voltage before servicing any operator station component. The lens typically snaps or threads into the operator housing without special tools. Inspect the lens retainer and housing for cracks or wear before reinstalling the assembly.

Technical Specifications

• Mounting Size: 30.5mm
• Length: 1.7 inches
• Width: 1.6 inches
• Height (Thickness): 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211320379

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM80
