Eaton 10250TM67 Standard Type Operator 30.5mm

Product Description

The EATON 10250TM67 is a standard-type operator designed for use with 30.5mm control station assemblies. Operators in this product family serve as the actuating mechanism for pushbuttons, selector switches, and similar control devices mounted in industrial control panels and operator stations. This component is installed by licensed electricians and control panel technicians working on industrial machinery, process equipment, and motor control systems. It is engineered to fit within the 10250T series control station product line.

This operator is suited for industrial and commercial electrical control applications where a 30.5mm mounting footprint is required. It mounts into standard 30.5mm panel cutouts and works within multi-element control station assemblies common in manufacturing, material handling, and process control environments. Electricians and automation technicians typically spec this part during panel builds or field replacements of worn or damaged operator heads.

Key Features

• Standard-type operator format for 30.5mm control stations
• Part of the EATON 10250T series operator station product line
• Designed for industrial control panel and operator station assemblies
• Compact and lightweight at 0.01 pounds

Compatibility

Designed as a standard-type replacement operator for 30.5mm industrial control station assemblies within the EATON 10250T series product family.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. Disconnect and lock out all power to the control panel before removing or installing any operator or control station component. Verify that the panel cutout is 30.5mm and that all contact block and legend plate accessories are compatible before completing the assembly.

Technical Specifications

• Mounting Size: 30.5mm
• Operator Type: Standard
• Weight: 0.01 pounds
• UPC: 78211322452

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM67
