Eaton 10250TM49 Standard Type Legend Plate 30.5mm

Product Description

The EATON 10250TM49 is a standard-type legend plate designed for use with 30.5mm pilot light assemblies and operator devices in industrial control panel applications. This small-format nameplate provides a labeled identification window that fits into compatible 10250T-series legend holders, giving electricians and panel builders a clean, professional way to identify pushbuttons, selector switches, and indicator lights on operator interface panels. At 0.01 pounds and measuring 1.7 x 1.6 x 0.1 inches, it installs quickly and requires no tools beyond what is needed for the host device assembly.

This legend plate is suited for use in industrial control panels, machine operator stations, and process control enclosures where 30.5mm mounting configurations are standard. It is typically installed during panel build or retrofitted during maintenance when existing legends need replacement or relabeling. Panel builders, industrial electricians, and MRO technicians working with EATON 10250T-series devices are the primary installers of this component.

Key Features

• Standard-type legend plate for 30.5mm pilot light and operator device assemblies
• Compact form factor at 1.7 x 1.6 x 0.1 inches for direct insertion into compatible legend holders
• Lightweight at 0.01 pounds, adding negligible load to panel door or enclosure
• Part of the EATON 10250T-series accessory family for industrial control applications

Compatibility

Designed as an OEM-style accessory for 30.5mm pilot light and operator device assemblies in the EATON 10250T-series product line.

Installation Notes

Installation of legend plates should be performed by a qualified electrician or panel builder. De-energize and lock out the control panel before servicing any operator device or legend holder. Legend plates are inserted into the legend window of the host device assembly and require no tools for the plate itself, though the surrounding device installation must comply with applicable NEC requirements for industrial control panels.

Technical Specifications

• Mounting Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322447

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM49
