Eaton 10250TM48 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM48 is a standard-type pilot light lens designed for 30.5mm push-button and pilot light assemblies used in industrial control panels and motor control centers. This small-format lens component fits into the 10250T series operator interface hardware, providing a clear or colored light-transmitting cover for indicator and pilot light stations. Electricians and controls technicians install this lens as part of routine panel maintenance or when replacing damaged indicator components. At 0.01 pounds and a compact footprint of 1.7 x 1.6 x 0.1 inches, it is a direct drop-in service part that requires no special tooling beyond basic hand tools.

This lens is suited for use in industrial and commercial control panel applications where 30.5mm operator devices are specified. Typical installations include motor starters, machine control enclosures, and automated equipment panels. It is installed by licensed electricians or qualified controls technicians during panel build, retrofit, or field repair work on 30.5mm push-button stations.

Key Features

• 30.5mm mounting format compatible with standard industrial operator interface assemblies
• Compact profile at 1.7 x 1.6 x 0.1 inches for low-profile panel installations
• Lightweight at 0.01 pounds — minimal impact on panel door weight
• Designed for use as a service replacement or original build component in control stations
• Part of the EATON 10250T series operator device product line

Compatibility

Designed as an OEM-style replacement lens for 30.5mm pilot light and push-button operator stations in the EATON 10250T series product family.

Installation Notes

Installation of this lens should be performed by a qualified electrician or controls technician. De-energize the control panel and follow applicable lockout/tagout procedures per OSHA and NEC guidelines before servicing any operator device. The lens typically snaps or threads into the pilot light body without special tools. Verify lens seating is secure before restoring power to the panel.

Technical Specifications

• Mounting Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322446

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM48
