Eaton 10250tm43 Legend Plate OPEN CLOSE

Product Description

The Eaton 10250TM43 is a push button legend plate for use with the 10250T series, selector switch, and roto-push operators. Eaton's 10250T line of 30.5 mm pushbuttons features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions.

• Half round plate for 30.5mm selector switches and roto-push operators
• OPEN - CLOSE legend
• Heavy-duty zinc die cast construction

Product Highlights

The EATON legend plate is a half round plate for 30.5mm selector switches and roto-push operators.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM43
• Country of Origin: United States

Technical Specifications

• Legend Color: White
• Legend: OPEN CLOSE
• Operator Type: Selector Switch/Roto-Push
• Series: 10250T
• Type: Standard
• Height: 1-3/4 in
• Width: 1-3/4 in
• Plate Shape: Half Round
• Material: Aluminum
• Field Color: Black
• Product Name: Eaton 10250T pushbutton legend plate
• Catalog Number: 10250TM43
• UPC: 782113224411
• Product Length/Depth: 1.8 in
• Product Height: 0.1 in
• Product Width: 1.5 in
• Compliances: CE Marked
• Certifications: CSA Certified UL Listed
• Product Type: Pushbutton accessory
• Used with: 10250T series, selector switch and roto-push operators
• Letter size: 5/32 in high
• Lettering color: White
• Product category: Legend plate
• Size: Standard, 1/2 round
• Brand: Eaton
• Country of Origin: United States
• Alternate Mfr Part Number: 10250TM43
• Dimensions: 0.01 in W X 1.80 in L
• Manufacturer Part Number: 10250TM43
• UPC Code: 782113224411
• Mounting Type: Panel
• Approval: UL, CSA, CE
• Length (in): 1.8
• Width (in): 1.5
• Height (in): 0.1
• For Use With: 10250T Series, Selector Switch and Roto-Push Operators
• Mpn: 10250TM43
• Upc: 782113224411
• Gtin: 782113224411
• Primary brand: Eaton
• Secondary brand: Cutler-Hammer
• Main function: Marking
• Functions: Half-round legend plate
• Shape: Half round legend
• Technical compatibility with: 10250 series
• Manufacturer product status: Commercialized
• Marking: "OPEN / CLOSE"
• Compatible with Series: 10250T
• Background Color: Black
• Keyway Type: Notch
• Language: English
• Overall Width: 1-1/2 in
• Panel Mounting Hole Diameter: 30 mm
• UNSPSC: 39121512
