Eaton 10250TM39 Standard Type Pilot Light Module

Product Description

The EATON 10250TM39 is a standard-type pilot light module designed for use in 30.5mm push button operator stations and control panel assemblies. This compact module provides a visual indication function within industrial control systems, fitting into the 10250T series operator interface lineup. It is installed by electricians and control panel builders working on machine control, motor control centers, and industrial automation enclosures. The module measures 1.8 inches long by 1.5 inches wide by 0.1 inches deep and weighs approximately 0.01 pounds, making it a lightweight, space-efficient component for dense panel layouts.

This pilot light module is suited for industrial and commercial control panel applications where a 30.5mm mounting footprint is required. Typical installations include operator stations on manufacturing equipment, motor control centers, and automation panels. It is intended for use with compatible 10250T series operator interface hardware and accessories within the same product family.

Key Features

• Standard-type pilot light module for 30.5mm operator stations
• Part of the EATON 10250T series operator interface system
• Compact profile: 1.8 x 1.5 x 0.1 inches for space-constrained panel layouts
• Lightweight construction at approximately 0.01 pounds
• Designed for consistent visual indication in industrial control environments

Compatibility

Designed as an OEM-style replacement or supplemental module for 30.5mm control station and push button operator assemblies within the 10250T series product family.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing or installing any pilot light module. Verify that the mounting cutout and operator station body are compatible with the 30.5mm format before installation. Do not exceed the electrical ratings specified for the operator station assembly.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Size: 30.5mm
• Length: 1.8 inches
• Width: 1.5 inches
• Height: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322438

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM39
