Eaton 10250TM32 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM32 is a standard-type pilot light lens designed for use with 30.5mm push-button and indicating light assemblies. This lens component mounts to the front of a pilot light operator or contact block assembly, providing a clear or colored light diffuser face for panel-mounted control station applications. Electricians and control panel builders install this part during new builds and replacement service on industrial control stations. The lens measures 1.7 inches in length, 1.6 inches in width, and 0.1 inches in depth, and weighs 0.1 pounds.

The 10250TM32 fits within the EATON 10250T series control station and operator family, which is commonly found in industrial and commercial electrical control panels. It is used in applications where visual indication is required at a push-button station, selector switch, or operator interface. Panel builders and industrial electricians use these lens components when replacing damaged or discolored lens faces on existing assemblies or when completing new control station builds.

Key Features

• Standard-type lens for 30.5mm pilot light and operator assemblies
• Compact form factor at 1.7 x 1.6 x 0.1 inches for panel-flush mounting
• Lightweight at 0.1 pounds for easy handling during panel assembly
• Compatible with EATON 10250T series control station hardware
• Direct OEM replacement design for field service and new construction

Compatibility

Designed as a standard OEM-style replacement lens for 30.5mm pilot light and indicating light operator assemblies in industrial control panel applications.

Installation Notes

Installation is performed by a licensed electrician or qualified control panel technician. De-energize and lock out the control panel in accordance with NFPA 70E lockout/tagout procedures before beginning any work on the assembly. The lens typically seats or snaps into the pilot light operator body and should be inspected for proper seating before restoring power. Do not over-force the lens during installation, as the component is a precision-fit plastic part.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Size: 30.5mm
• Length: 1.7 inches
• Width: 1.6 inches
• Depth: 0.1 inches
• Weight: 0.1 pounds
• UPC: 78211320365

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM32
