Eaton 10250TM30 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM30 is a standard-type pilot light lens designed for use in 30.5 mm push button and pilot light assemblies. This small-format lens fits into the 10250T series operator housing and provides the visible indicator face for control station applications. Electricians and panel builders use this lens when assembling or servicing indicating lights on industrial control panels, motor control centers, and machine control enclosures. At 0.010 pounds and measuring 1.7 inches by 1.6 inches by 0.1 inches, the lens is a compact, lightweight replacement or assembly component.

The 10250TM30 is suited for industrial and commercial electrical control applications where 30.5 mm operator devices are used. Typical installations include NEMA-rated control stations, operator interface panels, and machine-mounted enclosures. This lens is installed as part of a complete pilot light assembly alongside the appropriate lamp module, contact block, and operator body within the 10250T series platform.

Key Features

• Standard-type lens for 30.5 mm pilot light and push button assemblies
• Lightweight construction at 0.010 pounds for easy handling during panel assembly
• Compact profile: 1.7 inches x 1.6 inches x 0.1 inches
• Designed for use with the EATON 10250T series operator device platform
• UPC: 782113203636

Compatibility

Designed as an OEM-style component for use with EATON 10250T series 30.5 mm pilot light and push button operator assemblies in industrial control panel applications.

Installation Notes

Installation is typically performed by a licensed electrician. De-energize the control panel and verify absence of voltage before disassembling or reassembling any operator device. The lens snaps or threads into the operator body per the 10250T series assembly sequence — consult the manufacturer documentation for the correct assembly order. NEC Article 409 applies to industrial control panel wiring and assembly practices.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Diameter: 30.5 mm
• Dimensions (L x W x H): 1.7 inches x 1.6 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 782113203636

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM30
