Eaton 10250TM27 Standard Type Operator Module 30.5mm

Product Description

The EATON 10250TM27 is a standard-type operator module designed for use in 30.5mm pushbutton and selector switch assemblies. It serves as a mechanical or electrical interface component within industrial control stations, transmitting operator input to the control circuit. Built for demanding panel environments, this module mounts into compatible 30.5mm cutout enclosures and is installed by licensed electricians and industrial maintenance technicians. The compact form factor, with a footprint of approximately 1.7 x 1.6 inches and a depth of 0.1 inches, keeps panel real estate efficient while maintaining reliable operation in control circuits.

This operator module is suited for use in industrial control panels, machine tool stations, and process equipment enclosures requiring 30.5mm operator devices. It fits into standard 30.5mm mounting configurations found in light manufacturing, heavy industrial, and commercial building control applications. Typical installation scenarios include pushbutton stations on motor starters, conveyor control panels, and HVAC air-handling unit control enclosures. Electricians building or servicing operator stations will find this a direct-fit component for 30.5mm assemblies.

Key Features

• Standard-type module designed for 30.5mm operator device assemblies
• Compact profile: 1.7 x 1.6 x 0.1 inches for space-efficient panel layouts
• Lightweight construction at approximately 0.01 pounds
• Compatible with industrial control station enclosures requiring 30.5mm cutouts
• Designed for use in demanding panel and machine control environments

Compatibility

Designed as an OEM-style replacement or new-installation component for 30.5mm industrial operator device assemblies.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements. De-energize and lockout-tagout the control circuit before removing or installing any operator module. Verify the panel cutout is the correct 30.5mm diameter before mounting. Do not force the module into mismatched enclosures, as this can damage the contact block interface.

Technical Specifications

• Mounting Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322434

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM27
