Eaton 10250TM24 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM24 is a standard-type pilot light lens designed for use with 30.5mm push button and pilot light assemblies in industrial control applications. This replacement lens mounts directly to the front of a compatible operator unit, providing a clear or colored light transmission window for panel-mounted indicator lights. Compact and lightweight at 0.010 pounds, the lens measures 1.7 inches long by 1.6 inches wide by 0.1 inches thick. It is typically installed by electricians and control panel technicians during new panel builds or when replacing a damaged or worn lens in the field.

This lens is suited for use in industrial control panels, machine tool enclosures, and operator interface stations where 30.5mm pilot light assemblies are specified. It is commonly used in manufacturing, processing, and utility environments where panel-mounted indicators require periodic lens replacement due to physical damage, discoloration, or lens style changes.

Key Features

• Standard type lens designed for 30.5mm pilot light and push button assemblies
• Compact form factor: 1.7 inches x 1.6 inches x 0.1 inches
• Lightweight construction at 0.010 pounds for easy handling during panel work
• Drop-in replacement style simplifies field servicing without full operator disassembly

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and push button operator assemblies.

Installation Notes

Installation should be performed by a qualified electrician with the panel de-energized and locked out per NFPA 70E electrical safety procedures. The lens typically snaps or threads onto the front of the operator body — inspect the mounting retention tabs or threads for damage before installing. No special tools are required, but a clean, dry work surface helps prevent scratching the lens surface during installation.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Size: 30.5mm
• Length: 1.7 inches
• Width: 1.6 inches
• Height (Depth): 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211320359

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM24
