Eaton 10250TM23 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM23 is a standard-type pilot light lens designed for 30.5mm operator openings in industrial control stations and push button enclosures. This lens component fits into the 10250T series legend and lens assemblies, providing a clear or colored light window for panel-mounted indicator lights. Electricians and panel builders install this part during new control panel builds or as a direct replacement when existing lenses become cracked, discolored, or damaged. At 0.1 pounds and a compact footprint of 1.8 inches by 1.5 inches by 0.1 inches, it is a low-profile, lightweight component that drops into standard 30.5mm cutouts without modification.

This lens is suited for use in industrial control panels, machine operator stations, and process control enclosures where 30.5mm push button and pilot light hardware is installed. It is compatible with EATON 10250T series pilot light assemblies and is a common replacement item in manufacturing, utilities, and heavy-equipment control applications where panel components are subject to regular wear or UV exposure.

Key Features

• Standard 30.5mm form factor fits existing 10250T series pilot light assemblies
• Lightweight construction at 0.1 pounds minimizes panel door load
• Compact dimensions of 1.8 x 1.5 x 0.1 inches for low-profile mounting
• Direct replacement design requires no panel modification
• Suitable for industrial control station and push button enclosure applications

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and push button operator assemblies used in industrial control stations.

Installation Notes

Installation is typically performed by a licensed electrician or qualified panel technician. De-energize the control panel and follow LOTO (lockout/tagout) procedures before servicing any pilot light or push button assembly. The lens typically snaps or threads into the operator body; refer to the 10250T series assembly instructions for the correct removal and insertion method. Verify lens color and legend alignment before restoring power.

Technical Specifications

• Series: 10250T Standard Type
• Operator Opening Size: 30.5mm
• Dimensions (L x W x H): 1.8 inches x 1.5 inches x 0.1 inches
• Weight: 0.1 pounds
• UPC: 78211322433

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM23
