Eaton 10250TM19 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM19 is a standard-type replacement lens designed for 30.5mm pilot light and indicating light assemblies. This small-format optical component fits into the front bezel of panel-mount indicator lights, transmitting illumination from the lamp element to the operator or technician viewing the control panel. It is a direct-fit part used in industrial control panels, motor control centers, and machine operator stations. The lens measures 1.7 inches by 1.7 inches with a depth of 0.1 inches and weighs approximately 0.01 pounds, making it a lightweight but precise fitment component. Electricians and control panel technicians are the primary installers.

This lens is suited for industrial and commercial control panel applications where 30.5mm pilot device assemblies are used. Typical installations include motor starters, disconnect switch panels, conveyor controls, and process equipment operator interfaces. It is used wherever a standard-format indicating lens is needed to complete or restore a pilot light assembly to working condition.

Key Features

• Standard type lens for 30.5mm pilot light and indicator assemblies
• Compact profile at 1.7 x 1.7 x 0.1 inches for direct panel-mount fitment
• Lightweight construction at approximately 0.01 pounds
• Designed for industrial control panel and operator station use

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and indicating light assemblies used in industrial control panel applications.

Installation Notes

Installation is typically performed by a licensed electrician or qualified control panel technician. De-energize the control panel and follow applicable NFPA 70E lockout/tagout procedures before servicing any pilot device assembly. The lens typically snaps or threads into the pilot light bezel; consult the assembly documentation for the specific retention method. Avoid overtightening any retaining ring to prevent cracking the lens body.

Technical Specifications

• Pilot Device Size: 30.5mm
• Length: 1.7 inches
• Width: 1.7 inches
• Height (Depth): 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211320358

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM19
