Eaton 10250TM17 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM17 is a standard-type pilot light lens designed for 30.5mm control station operators. This lens fits into the 10250T series operator lineup and serves as a replacement or spare component for panel-mounted indicator lights and push-button assemblies. It provides the optical interface between the lamp source and the operator face, transmitting the illuminated status signal to the technician or panel operator. Electricians and controls technicians working on industrial control panels, machine tool stations, and process equipment enclosures are the primary installers of this component.

This lens is suited for use in industrial and commercial control panel applications where 30.5mm push-button and pilot light operators are installed. It is a standard-type replacement lens, making it appropriate for maintenance stock in facilities that run EATON 10250T series control stations. Typical installations include motor control centers, operator interface stations, and industrial machinery control enclosures where panel-mount operator devices require periodic lens replacement or color change.

Key Features

• Standard-type lens format for 30.5mm operator mounting diameter
• Designed for the EATON 10250T series control station platform
• Compact profile at 0.1 inches thickness
• Lightweight construction at 0.1 pounds for easy handling during panel work
• Direct OEM-style replacement for maintenance and repair applications

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and control station operators.

Installation Notes

Installation is performed by a licensed electrician or qualified controls technician. De-energize the control panel and lock out the power source per NFPA 70E safe work practices before servicing any operator device or lens assembly. The lens typically snaps or threads into the operator cap without special tooling. Verify the lens color and style match the original operator specification before completing the installation.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Diameter: 30.5mm
• Package Dimensions (L x W x H): 5 inches x 4 inches x 0.1 inches
• Weight: 0.1 pounds
• UPC: 78211322429

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM17
