Eaton 10250TM14 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM14 is a standard-type pilot light lens designed for 30.5mm operator controls used in industrial and commercial electrical control panels. This replacement lens fits into the 10250T series pushbutton and pilot light assemblies, providing the transparent or translucent cover through which indicator lamp illumination is visible. Electricians and control panel technicians install this component when a lens is cracked, discolored, or missing from an existing assembly. At 0.1 pounds and compact dimensions, it is a direct drop-in service part that restores full indicator functionality without replacing the entire operator unit.

The 10250TM14 lens is suited for use in 30.5mm 10250T series control stations found in industrial machinery, motor control centers, and panel board assemblies in both light manufacturing and heavy industrial environments. It is installed during routine maintenance, panel refurbishment, or field repair of operator interface hardware. Licensed electricians performing control panel service work are the primary installers of this component.

Key Features

• Standard-type lens for 30.5mm 10250T series pilot light assemblies
• Compact form factor fits flush within existing operator hardware
• Lightweight at 0.1 pounds for easy field handling and stocking
• Direct replacement restores indicator visibility without full assembly swap

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and pushbutton operator assemblies.

Installation Notes

Installation should be performed by a qualified electrician with the control panel de-energized and locked out per NFPA 70E lockout/tagout procedures. Snap or thread the lens into the operator body according to the existing assembly configuration. Inspect the lamp socket and operator body for damage before reinstalling the lens. Verify indicator function after restoring power to the circuit.

Technical Specifications

• Series: 10250T Standard Type
• Operator Size: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.6 inches x 0.1 inches
• Weight: 0.1 pounds
• UPC: 78211320355

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM14
