Eaton 10250TM11 Standard Type Pilot Light Module

Product Description

The EATON 10250TM11 is a standard-type pilot light module designed for use in 30.5mm operator control stations and pushbutton assemblies. This module mounts to compatible operator hardware and provides a visible status indication for panel-mounted control circuits. It is sized at 1.7 inches long by 1.6 inches wide by 0.1 inches deep and weighs approximately 0.01 pounds, making it a compact, low-profile component suited for tight enclosure layouts. Licensed electricians and industrial control technicians typically install this type of module during new panel builds or field replacements on existing control stations.

This pilot light module is intended for industrial and commercial control panel applications where 30.5mm format operator devices are used. Typical installations include motor control centers, machine control panels, and operator interface stations in manufacturing, process control, and utility environments. The module integrates with the 10250T series stackable operator hardware common in industrial settings.

Key Features

• Standard-type pilot light module for 30.5mm operator control stations
• Compact form factor: 1.7 x 1.6 x 0.1 inches for space-efficient panel layouts
• Lightweight construction at approximately 0.01 pounds
• Designed for integration with 10250T series operator hardware
• UPC: 78211320352

Compatibility

Designed as an OEM-style replacement or new-installation module for 30.5mm format pilot light operator assemblies in industrial control panel applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC guidelines and local electrical codes. De-energize and lock out the control panel before removing or installing any pilot light module. Verify that the operator body and module are fully seated and mechanically secured before restoring power. Do not force the module into place; misalignment can damage the contact interface.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Format: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211320352

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM11
