Eaton 10250TLP76 Jumbo Type Pilot Light Lens

Product Description

The EATON 10250TLP76 is a jumbo type pilot light lens designed for use with 10250T and 10250E series indicating lights and control stations. This lens cover mounts over a pilot light assembly to provide a visible indicator light for control panel and machine status applications. Electricians and panel builders install this component as part of operator interface assemblies on industrial control equipment. It provides a rugged, clearly visible signal point at the operator station without adding complexity to the wiring or control circuit.

This lens is suited for use in industrial and commercial control applications where jumbo-size operator devices are required. Typical installations include machine control panels, motor control centers, and process equipment operator stations. The jumbo form factor offers improved visibility at a distance, making it appropriate for larger workspaces or environments where standard-size indicators may be difficult to see clearly.

Key Features

• Jumbo type form factor for improved visibility in industrial environments
• Designed for use with 10250T and 10250E series pilot light assemblies
• Lens cover construction protects the light assembly at the operator interface
• Compatible with standard control panel and machine station installations

Compatibility

Designed as an OEM-style replacement lens for jumbo type pilot light and indicating light assemblies used in industrial control panels and operator stations.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. Disconnect and lock out all power to the control panel before servicing or replacing any operator device components. Ensure the lens is fully seated and secured to the pilot light body before restoring power. Inspect surrounding gaskets or seals during installation if the application requires an environmental rating.

Technical Specifications

• Type: Jumbo Type Pilot Light Lens
• Weight: 0.1 pounds
• UPC: 78211332894

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TLP76
