Eaton 10250TLL Indicating Light Unit

Product Description

The EATON 10250TLL is an indicating light unit designed for use in industrial control panels and operator interface stations. Indicating lights provide a clear visual signal of equipment status, circuit conditions, or operational states on control enclosures and switchboards. This unit is built to integrate with 10250T-series push button and pilot device assemblies, making it a common component in industrial electrical control applications. Licensed electricians and industrial maintenance technicians typically handle specification and installation of these devices.

The 10250TLL is suited for use in industrial and commercial control panel environments where reliable visual indication is required. It fits within the 10250T-series operator interface system, which is a widely used platform for push buttons, selector switches, and pilot lights in manufacturing, process control, and related applications. Installers should verify the correct lens color, voltage, and lamp type for the specific control circuit before ordering.

Key Features

• Part of the 10250T-series pilot device platform for modular control panel buildouts
• Designed for indicating light applications in industrial control enclosures
• Compact form factor suitable for panel door or operator station mounting
• Supports integration with compatible 10250T-series operator interface components

Compatibility

Designed as an OEM-style replacement or new-installation component for use within EATON 10250T-series industrial control panel pilot device assemblies.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing or installing any pilot device. Verify voltage rating and lamp compatibility before completing the circuit connection. Secure the unit per the manufacturer's mounting guidelines to prevent vibration-related failure.

Technical Specifications

• Weight: 0.02 pounds
• UPC: 78211322423

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TLL
