Eaton 10250TLG Cap Type 30.5mm Push Button

Product Description

The EATON 10250TLG is a cap-type push button operator built for the 30.5mm mounting diameter format used in industrial control panels and operator interface stations. This component serves as the actuator portion of a push button assembly, providing the physical interface between the operator and the underlying contact block or switch mechanism. It is typically installed by licensed electricians and industrial maintenance technicians working on control panels, machine tool stations, and motor control centers. The 30.5mm mounting format is a widely used heavy-duty industrial standard suited for demanding environments.

This cap-type operator is used in industrial and commercial electrical control applications where a robust, panel-mount push button actuator is required. Typical installation scenarios include machine control panels, assembly line operator stations, and motor control enclosures. The 30.5mm body size accommodates standard panel cutouts used in heavy-duty industrial operator interface assemblies.

Key Features

• Cap-type actuator design for standard push button assemblies
• 30.5mm mounting diameter fits heavy-duty industrial panel cutouts
• Modular design mates with compatible 10250T series contact blocks
• Suitable for operator interface and machine control panel installations

Compatibility

Designed as an OEM-style operator component for 30.5mm heavy-duty industrial push button assemblies. Consult the 10250T series documentation for compatible contact blocks and legend plates.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing or installing any push button operator or contact block. Verify the panel cutout diameter matches the 30.5mm mounting requirement before installation. Do not over-tighten the mounting hardware, as this may crack the operator body or distort the panel surface.

Technical Specifications

• Operator Type: Cap Type
• Mounting Diameter: 30.5mm
• UPC: 78211320426

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TLG
