Eaton 10250TLB Cap Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TLB is a cap type pilot light lens designed for use with 30.5mm pilot devices and indicating lights in industrial control panel applications. This lens cap fits over the lamp module of a pilot light assembly, providing a colored or clear light diffuser that signals equipment status at a glance. Electricians and industrial control panel builders install this component during new panel construction or as a direct replacement when an existing lens is cracked, faded, or missing. Its compact form factor and lightweight construction make handling and installation straightforward in tight enclosure spaces.

The 10250TLB is suited for use in industrial and commercial electrical control panels where 30.5mm pilot light assemblies are standard. Typical applications include machine control stations, motor control centers, and operator interface panels found in manufacturing, processing, and HVAC mechanical rooms. This lens cap is installed by licensed electricians or qualified control panel technicians as part of routine panel maintenance or new panel builds.

Key Features

• Cap type lens designed for 30.5mm pilot light assemblies
• Compact size fits standard industrial control panel cutouts
• Lightweight at 0.020 pounds for easy handling in confined panel spaces
• Direct replacement for damaged or worn pilot light lens caps
• Compatible with EATON 10250T series pilot device assemblies

Compatibility

Designed as an OEM-style replacement lens cap for 30.5mm industrial pilot light assemblies commonly used in control panel applications.

Installation Notes

Installation is performed by a licensed electrician or qualified control panel technician. Always de-energize the control panel and follow lockout/tagout procedures per NFPA 70E before servicing any pilot device or lens component. The lens cap typically snaps or threads onto the pilot light body without special tools. Verify the lens cap seats fully and securely before restoring power to the panel.

Technical Specifications

• Pilot Device Size: 30.5mm
• Lens Style: Cap Type
• Length: 1.6 inches
• Width: 1.0 inches
• Height: 0.5 inches
• Weight: 0.020 pounds
• UPC: 78211320424

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TLB
