Eaton 10250TL37 Jumbo Type 30.5mm Pilot Light Lens

Product Description

The EATON 10250TL37 is a jumbo-type lens designed for 30.5 mm pilot light and pushbutton operator assemblies. This replacement lens fits into the 10250T series operator platform and provides a clear or colored light-diffusing cover for indicator lamp units used in industrial control panels and machine operator stations. Electricians and panel builders install this component when replacing damaged or discolored lenses on existing assemblies. At 0.1 inches thick and just 0.02 pounds, it is a lightweight, precision-fit part intended for fast field or shop replacement.

This lens is suited for use in industrial control panel operator interfaces, motor control centers, and machine tool stations where 30.5 mm mounting formats are standard. It is compatible with the EATON 10250T series of jumbo pilot devices and operator assemblies. Typical installations are found in manufacturing, process control, and heavy industrial environments where panel-mount indicators must withstand repeated contact and maintain clear visibility under varied lighting conditions.

Key Features

• Jumbo-type 30.5 mm format fits standard industrial operator cutouts
• Designed for the EATON 10250T series pilot light and pushbutton assemblies
• Low profile at 0.1 inches thick for flush panel integration
• Lightweight construction at 0.02 pounds for easy handling during replacement
• Snap-fit or twist-lock style installation typical of 10250T series components

Compatibility

Designed as a replacement lens for EATON 10250T series jumbo-type 30.5 mm pilot light and operator assemblies used in industrial control panel applications.

Installation Notes

De-energize the control panel and follow applicable NFPA 70E lockout/tagout procedures before servicing any pilot light or operator assembly. This lens is installed by a licensed electrician or qualified panel technician. Remove the existing lens by releasing the retaining clip or rotating to unlock per the assembly design, then seat the replacement lens firmly until secured. Do not force the lens if resistance is felt, as misalignment can crack the component.

Technical Specifications

• Mounting Size: 30.5 mm
• Type: Jumbo
• Dimensions (L x W x H): 2.2 inches x 2.2 inches x 0.1 inches
• Weight: 0.02 pounds
• UPC: 78211312473

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TL37
