Eaton 10250TL36 Jumbo Type Pilot Light Lens 30.5 Mm

Product Description

The EATON 10250TL36 is a jumbo-type pilot light lens designed for 30.5 mm operator openings in industrial control panels and operator interface assemblies. This lens fits into the 10250T series pushbutton and pilot light lineup, providing a visual indicator surface for panel-mounted signaling devices. Electricians and control panel technicians install this component when building or servicing operator stations on machine control enclosures, motor control centers, and similar industrial equipment. The lens measures 2.2 inches in length, 2.2 inches in width, and 0.1 inches in depth, and weighs 0.02 pounds.

This lens is suited for industrial and commercial control panel applications where 30.5 mm jumbo-style pilot light assemblies are specified. It is commonly installed in manufacturing facilities, process control environments, and equipment panels that require a clearly visible indicator. Panel builders and licensed electricians select this part during new panel construction or as a field replacement when an existing lens is cracked, discolored, or damaged.

Key Features

• Jumbo-type lens format for 30.5 mm pilot light operator openings
• Compact profile at 0.1 inches depth for flush panel mounting
• Lightweight construction at 0.02 pounds for easy handling during installation
• Part of the EATON 10250T series operator interface product family

Compatibility

Designed as an OEM-style replacement lens for 30.5 mm jumbo-type pilot light assemblies in industrial control panel applications.

Installation Notes

Installation is typically performed by a licensed electrician following applicable NEC guidelines. De-energize and lock out the control panel before removing or replacing any operator interface component. The lens snaps or threads into the pilot light body depending on the specific assembly configuration. Verify the replacement lens matches the original operator opening size and series before installation.

Technical Specifications

• Operator Opening Size: 30.5 MM
• Type: Jumbo
• Length: 2.2 inches
• Width: 2.2 inches
• Depth: 0.1 inches
• Weight: 0.02 pounds
• UPC: 78211312472

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TL36
