Eaton 10250TA15 30.5mm Pilot Light Lens Cap

Product Description

The EATON 10250TA15 is a lens cap accessory designed for 30.5mm pilot light and indicating light assemblies used in industrial control panels and operator interface stations. This component fits over the lamp holder to provide colored or clear light diffusion, helping operators identify equipment status at a glance. It is a standard accessory part within the Eaton 10250T series of 30.5mm heavy-duty control devices and is typically installed by industrial electricians and control panel builders during panel assembly or field maintenance.

The 10250TA15 is suited for use in industrial environments where 30.5mm panel cutout pilot devices are specified. Common applications include motor control centers, machine control panels, and operator consoles in manufacturing and process control facilities. This lens cap is part of the Eaton 10250T series accessory line, which is widely used in both original equipment manufacturer builds and replacement service work.

Key Features

• Designed for 30.5mm pilot light and indicating light assemblies
• Part of the Eaton 10250T series heavy-duty control device platform
• Compact form factor fits within standard 30.5mm panel cutout installations
• Lightweight construction at 0.15 pounds for easy handling during panel work

Compatibility

Designed as an OEM-style accessory replacement for 30.5mm pilot light and indicating light assemblies within the Eaton 10250T series control device product line.

Installation Notes

Installation is typically performed by a licensed electrician or qualified control panel technician. De-energize and lock out the control panel before servicing any pilot device or replacing lens components, following applicable NFPA 70E arc flash and lockout/tagout procedures. Ensure the lens cap is fully seated on the lamp holder before restoring power to the panel.

Technical Specifications

• Mounting Size: 30.5mm
• Dimensions (L x W x H): 2.2 inches x 1.9 inches x 1.9 inches
• Weight: 0.15 pounds
• UPC: 78211320454

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TA15
