Eaton 10250t6371 Selector Switch Operator 30.5mm 240V

Product Description

The EATON 10250t6371 is a heavy-duty oil and watertight illuminated selector switch operator designed for industrial control panel applications. Built to the 10250T series standard, this operator features a 30.5 mm mounting footprint, maintained contact mode, and a 2-position, 60-degree throw configuration with a Cam Code 1 setting. The die cast zinc housing carries a polished chrome finish and meets NEMA 3, 3R, 4, 4X, 12, 13, and IP66 ratings, making it suitable for wash-down, outdoor, and corrosive-environment installations. The integrated incandescent lamp operates at 240 VAC or VDC. Licensed electricians and industrial controls technicians are the typical installers.

This selector switch operator is used in heavy industrial, manufacturing, and process control environments where panel-mounted operator controls must withstand exposure to oil, water, and dust. The NEMA 4X and IP66 ratings qualify it for wash-down zones and outdoor enclosures. Its 2-position maintained action makes it appropriate for run or stop, local or remote, and similar latching control functions. The 30.5 mm body fits standard 10250T series cutouts found in industrial control panels and machine operator stations.

Key Features

• 30.5 mm operator size fits standard 10250T series panel cutouts
• 2-position maintained contact mode with 60-degree throw
• Incandescent illuminated operator rated at 240 VAC or VDC
• NEMA 3, 3R, 4, 4X, 12, 13 and IP66 enclosure rating for oil, water, and dust resistance
• Die cast zinc construction with polished chrome finish for durability in harsh environments
• Cam Code 1 configuration for consistent contact sequencing

Compatibility

Designed as an OEM-style operator for EATON 10250T series heavy-duty control station assemblies requiring a 30.5 mm illuminated selector switch operator.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NFPA 70 (NEC) requirements. De-energize and lock out the control panel before removing or installing any operator component. Ensure the panel enclosure maintains its NEMA or IP rating integrity after installation by using appropriate sealing hardware. Do not exceed the 240 VAC or VDC voltage rating of the lamp circuit.

Technical Specifications

• Series: 10250T
• Type: Heavy Duty Oil and Watertight Illuminated
• Operator Size: 30.5 mm
• Number of Positions: 2
• Contact Mode: Maintained
• Throw: 60 degrees
• Cam Code: 1
• Lamp Type: Incandescent
• Voltage Rating: 240 VAC or VDC
• Enclosure Rating: NEMA 3, 3R, 4, 4X, 12, 13, IP66
• Housing Material: Die Cast Zinc
• Finish: Polished Chrome
• Warranty: 1 year

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250t6371
