Eaton 10250T6361 Lever Type Knob Operator

Product Description

The EATON 10250T6361 is a lever type knob operator designed for use with 10250T series industrial pushbutton and selector switch assemblies. This component serves as the actuating interface between the operator and the control station, allowing manual input to the switch mechanism beneath. It is a direct-fit operator part intended for installation by licensed electricians and industrial maintenance technicians working on control panel assemblies and operator interface stations. The lever knob format provides a positive grip surface suited for environments where gloved operation or quick actuation is required.

The 10250T6361 lever type knob is applicable in industrial control stations, machine tool panels, and operator interface enclosures where 10250T series selector or pushbutton operators are used. It is suited for both light manufacturing and heavy industrial environments. Installation is performed during panel assembly or as a field replacement when an existing knob operator is damaged or worn.

Key Features

• Lever type knob design provides positive manual actuation for selector and pushbutton operators
• Part of the EATON 10250T series modular control station system
• Compact and lightweight at 0.35 pounds for easy field handling
• Designed for replacement or new-build industrial control panel applications

Compatibility

Designed as an OEM-style replacement lever type knob operator for EATON 10250T series control station assemblies. Specific compatible operator heads and contact blocks were not listed in the available product data; verify fitment against the 10250T series product documentation before installation.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and local codes. De-energize the control panel and verify zero voltage at the control station before removing or installing any operator component. Confirm that the lever knob mates correctly with the underlying switch operator body before securing. Do not force-fit the knob onto an incompatible operator stem.

Technical Specifications

• Operator Style: Lever Type Knob
• Weight: 0.35 pounds
• UPC: 78211336165

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250T6361
