Eaton 10250T32B Mushroom Head Pushbutton 30.5mm

Product Description

The EATON 10250T32B is a mushroom head pushbutton operator designed for industrial control panel applications. This 30.5mm operator mounts into standard 30.5mm panel cutouts and provides a large-surface actuator head for emergency stop or other critical control functions. The unit weighs 0.3 pounds and fits within a compact envelope, making it suitable for dense panel layouts. Licensed electricians and industrial control panel builders are the primary installers of this type of operator.

The 10250T32B is used in industrial and commercial control panel assemblies where a mushroom head actuator is required. The enlarged head profile offers a broad contact surface for quick, positive actuation. Typical applications include machine control stations, operator interface panels, and process control enclosures in manufacturing and industrial plant environments.

Key Features

• 30.5mm mounting diameter fits standard industrial panel cutouts
• Mushroom head actuator design provides large, positive contact surface
• Compact body dimensions of 3.4 inches x 2.3 inches x 2.1 inches
• Lightweight construction at 0.3 pounds
• Designed for use with EATON 10250T series contact blocks and accessories

Compatibility

Designed as an OEM-style operator for 30.5mm industrial pushbutton control stations, compatible with standard 10250T series contact blocks and panel assemblies accepting a 30.5mm mounting footprint.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize and lockout/tagout the control panel before installing or replacing any operator or contact block. Ensure the panel cutout diameter matches the 30.5mm mounting specification before installation. Do not over-tighten the mounting hardware, as this may crack the operator body or distort the panel surface.

Technical Specifications

• Actuator Type: Mushroom Head
• Mounting Diameter: 30.5mm
• Length: 3.4 inches
• Width: 2.3 inches
• Height: 2.1 inches
• Weight: 0.3 pounds
• UPC: 78211313418

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250T32B
