Eaton 10250T31R Extended Type Pilot Light 30.5mm

Product Description

The EATON 10250T31R is an extended-type pilot light operator designed for use in industrial control panel applications. Part of the 10250T series, this 30.5mm operator mounts in standard 30.5mm cutout panels and provides a visual status indication for control circuits. It is installed by licensed electricians and industrial maintenance technicians working on motor control centers, machine control panels, and process equipment enclosures. The compact form factor and extended operator style make it compatible with a wide range of 10250T series bases and contact blocks commonly found in heavy-duty industrial environments.

This pilot light operator is suited for use in industrial and commercial control panel installations where 30.5mm operator devices are specified. Typical applications include machine tool control, conveyor systems, pump stations, and other process control assemblies requiring panel-mounted status indication. The 10250T31R is designed for installations where an extended operator profile is required to meet panel layout or accessibility specifications.

Key Features

• Extended-type operator style for 30.5mm panel cutout mounting
• Part of the EATON 10250T series heavy-duty industrial operator platform
• Compact package dimensions suitable for dense panel layouts
• Lightweight construction at 0.3 pounds for easy panel installation
• Compatible with 10250T series bases and contact block assemblies

Compatibility

Designed as an OEM-style replacement or new-installation operator for 30.5mm industrial control panels using EATON 10250T series components.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and local codes. De-energize the control panel and lock out the power source before removing or installing any panel operator device. Verify the panel cutout is the correct 30.5mm diameter before mounting. Follow the manufacturer documentation for torque and assembly sequence when mating with 10250T series base units.

Technical Specifications

• Operator Type: Extended Type
• Mounting Diameter: 30.5mm
• Package Dimensions (L x W x H): 2.4 inches x 2.1 inches x 3.4 inches
• Weight: 0.3 pounds
• UPC: 78211335787

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250T31R
