Eaton 10250T10 30.5mm Indicator Lens

Product Description

The EATON 10250T10 is a 30.5mm indicator lens designed for use with Eaton 10250T series pilot light and pushbutton assemblies. This lens component mounts into a compatible operator or legend plate housing to provide a visible light window for panel indicators in control and automation applications. Licensed electricians and panel builders install this lens when servicing or building industrial control panels, machinery enclosures, and operator interface stations. It is a direct replacement or spare part for existing assemblies that require a fresh lens due to damage, discoloration, or configuration change.

The 10250T10 lens is suited for industrial control panel applications across manufacturing, process automation, and machinery markets. It fits into 30.5mm cutout assemblies within the Eaton 10250T series lineup, making it a practical stock item for panel shops and electrical contractors that regularly service or build control stations. It is appropriate for both new panel construction and field replacement use.

Key Features

• 30.5mm size fits standard 30.5mm panel cutout assemblies
• Designed for use with Eaton 10250T series pilot light and pushbutton operators
• Compact form factor suitable for dense control panel layouts
• Lightweight construction at 0.25 pounds
• Direct OEM-style replacement for worn or damaged lens components

Compatibility

Designed as an OEM-style replacement lens for 30.5mm Eaton 10250T series pilot light and pushbutton assemblies in industrial control panel applications.

Installation Notes

Installation is typically performed by a licensed electrician or qualified panel builder. De-energize the control panel and follow applicable NFPA 70E lockout/tagout procedures before servicing any operator or indicator assembly. Snap or thread the lens into the compatible operator housing according to the assembly instructions for the specific 10250T series unit. Verify the lens is fully seated and secure before restoring power to the panel.

Technical Specifications

• Series: 10250T
• Mounting Size: 30.5mm
• Dimensions (L x W x H): 2.2 inches x 1.9 inches x 1.9 inches
• Weight: 0.25 pounds
• UPC: 78211363133

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250T10
