Eaton 06Z-L66-BG Female Ors Swivel 45 Elbow 6mm Steel

Product Description

The EATON 06Z-L66-BG is a female ORS swivel 45-degree elbow hydraulic hose fitting machined from steel. It connects a hydraulic hose to a port or component at a 45-degree angle, reducing stress on the hose and allowing cleaner routing in tight installations. The fitting uses an O-ring face seal (ORS) design, which provides a leak-resistant metal-to-metal seat backed by an elastomeric O-ring. The FOR-SEAL shaft type is compatible with standard ORS port configurations. Thread size is 11/16-16 with a hose size of 6 mm. The hex size measures 13/16 inches, accommodating a standard wrench for assembly. Hydraulic technicians and equipment mechanics install this type of fitting on mobile hydraulic systems, industrial machinery, and fluid power circuits.

This fitting is suited for hydraulic plumbing applications where a 45-degree directional change is required at the hose-to-port connection. Typical installations include mobile equipment such as loaders, excavators, agricultural machinery, and industrial hydraulic power units. The swivel feature allows the hose end to be oriented during installation without twisting the hose body, which is important for maintaining proper hose lay and avoiding premature wear. It is appropriate for use in medium- to high-pressure hydraulic circuits where ORS port connections are specified.

Key Features

• Female ORS swivel design provides leak-resistant O-ring face seal connection
• 45-degree elbow angle reduces hose stress and improves routing in confined spaces
• Swivel end allows hose orientation adjustment during assembly without twisting the hose
• Steel construction suited for hydraulic fluid service in demanding environments
• FOR-SEAL shaft type compatible with standard ORS port interfaces
• 13/16 inch hex for standard wrench installation

Compatibility

Designed as an OEM-style replacement hydraulic hose fitting for systems using female ORS swivel connections with an 11/16-16 thread size and 6 mm hose size.

Installation Notes

Installation should be performed by a qualified hydraulic technician or mechanic. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Clean all mating surfaces and inspect the O-ring for damage before assembly. Tighten to the fitting manufacturer's standard torque guidelines for the connection size, and verify there are no leaks before returning the system to service.
