Eaton 06Z-666-BG Hydraulic Hose Female Swivel 90 Elbow

Product Description

The EATON 06Z-666-BG is a female swivel 90-degree elbow hydraulic hose fitting manufactured from steel and built to SAE J1176 standards. It accommodates a 3/8-inch hose diameter with a 0.375-inch inside diameter and 0.375-inch outside diameter, connecting via a 9/16-18 threaded end. The overall length is 2.21 inches and the fitting weighs 0.21 pounds. Part of the EATON Z Series, this fitting is installed by hydraulic technicians and equipment service professionals working on mobile or industrial hydraulic systems where a right-angle swivel connection is required to relieve hose stress and accommodate routing constraints.

This fitting is designed for use in hydraulic hose assemblies where a 90-degree directional change is needed at the hose termination point. The swivel design allows the hose to rotate freely after installation, preventing hose twist and reducing wear. Typical applications include mobile equipment, industrial machinery, and hydraulic power units where hose routing must navigate tight or angled spaces. Compatible hose series include EC110, EC115, EC118, EC210, EC215, H0105, H0106, H104, H115, H116, H145, H145R, H1571, H1776, H1777, H1812, H190, H190H, and H1981, with size ranges as specified by EATON for each series.

Key Features

• Female swivel 90-degree elbow design reduces hose stress at connection points
• Steel construction for durability in high-pressure hydraulic environments
• SAE J1176 compliant — meets industry standards for hydraulic fittings
• 9/16-18 threaded connection for secure, leak-resistant attachment
• 11/16-inch hex size for standard wrench installation
• Z Series fitting compatible with a wide range of EATON hose assemblies

Compatibility

Designed for use with EATON hose series EC110, EC115, EC118, EC210, EC215, H0105 (-06 thru -12, -20), H0106 (-04 thru -10), H104, H115 (-04 thru -20), H116 (-04, -06, -08), H145, H145R, H1571 (-12 only), H1776 (-04 thru -20), H1777 (-04, -06, -08), H1812 (-04 thru -20), H190, H190H, and H1981 (-04), as specified by EATON for the Z Series in SAE configuration.

Installation Notes

Installation should be performed by a qualified hydraulic technician. Depressurize the hydraulic system completely and relieve all residual pressure before disconnecting or installing any fitting. Use a properly sized wrench on the 11/16-inch hex to tighten the fitting — do not over-tighten or use the hose body as a torque surface. Follow SAE J1176 guidelines and applicable equipment manufacturer service procedures during assembly.
