Eaton 04Z-L64-BG Female Ors Swivel 45 Elbow Fitting

Product Description

The EATON 04Z-L64-BG is a female ORS swivel 45-degree elbow hydraulic hose fitting manufactured from steel. It connects a hose end to a hydraulic port at a 45-degree angle, reducing stress on the hose and improving routing in tight installations. The fitting uses a 9/16-18 thread size with a FOR-SEAL shaft type, designed for leak-free sealing at the O-ring face seal interface. At 0.11 pounds and compact overall dimensions, it suits inline hydraulic circuit plumbing where straight adapters are impractical. Hydraulic technicians and equipment mechanics install this fitting on mobile and industrial hydraulic systems.

This fitting is used in hydraulic hose assemblies requiring a 45-degree directional change at the port connection. Typical applications include mobile equipment, construction machinery, agricultural equipment, and industrial hydraulic circuits. The swivel design allows the hose to be oriented after the fitting is torqued to the port, simplifying routing and reducing torsional load on the hose assembly. The 4 mm hose size designation and 9/16-inch hose diameter make it suitable for medium-pressure hydraulic lines in these environments.

Key Features

• Female ORS swivel design with FOR-SEAL shaft type for O-ring face seal connections
• 45-degree elbow configuration reduces hose strain and supports clean routing
• 9/16-18 thread size for secure, leak-resistant port engagement
• Steel construction for durability in hydraulic service environments
• Swivel body allows hose orientation adjustment after port installation
• Compact form factor: 2.83 inches length, 0.88 inches width, 1.51 inches height

Compatibility

Designed as an OEM-style replacement fitting for hydraulic hose assemblies using female ORS swivel connections with a 9/16-18 thread and 4 mm hose size designation.

Installation Notes

Installation should be performed by a qualified hydraulic technician or mechanic. Depressurize and de-energize the hydraulic system completely before removing or installing any fittings. Inspect the O-ring and sealing surfaces for damage before assembly, and replace the O-ring if any deformation or nicks are present. Refer to the equipment manufacturer specifications and applicable hydraulic system standards for proper port torque procedures.
