Eaton 04Z-60C-BG Male Sae 37 Jic Rigid Hose Fitting

Product Description

The EATON 04Z-60C-BG is a male SAE 37-degree JIC rigid fitting designed for hydraulic hose assemblies. It provides a leak-resistant flared connection between a hydraulic hose and a mating JIC female swivel or rigid port. Constructed from steel, this fitting is built to handle the pressure demands of industrial and mobile hydraulic systems. The metric thread size is M18 x 1.50, and the hose size is 4 mm with a hose diameter of 15/32 inches. The hex size measures 7/8 inches, allowing standard wrench engagement during installation. Hydraulic technicians and fluid power specialists are the primary installers of this component.

This fitting is suited for use in mobile equipment, industrial machinery, and hydraulic power units where a reliable SAE 37-degree JIC connection is required. The rigid style does not swivel after installation, making it appropriate for fixed-orientation hose routing. The metric thread configuration makes it compatible with metric-ported components and assemblies common in European-designed equipment and machinery. It is sold individually as a single-unit replacement fitting.

Key Features

• SAE 37-degree JIC flare seat provides a secure, leak-resistant metal-to-metal seal
• Steel construction for durability in high-pressure hydraulic environments
• M18 x 1.50 metric thread size for compatibility with metric-ported components
• Rigid fitting orientation for fixed hose routing applications
• 7/8-inch hex size accommodates standard open-end or combination wrenches
• Fits 4 mm hose size with a 15/32-inch hose diameter

Compatibility

Designed as an OEM-style replacement rigid JIC fitting for hydraulic hose assemblies requiring a male SAE 37-degree JIC end with M18 x 1.50 metric threads and a 4 mm hose size.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Use two wrenches when tightening to prevent hose or fitting rotation, and torque to the fitting manufacturer's published specifications for the thread and material combination. Inspect the JIC flare seat for damage before assembly to ensure a proper seal.
