E-flex 81032 Nonmetallic Liquidtight Conduit 1 in 100 Ft

Product Description

The E-FLEX 81032 is a general-purpose, nonmetallic liquidtight conduit (Type NM) manufactured from PVC and designed to protect wiring from abrasion, mild acids, alkaline environments, oils, and sunlight exposure. Supplied in a 100-foot coil at 1-inch trade size, this conduit carries both UL and CSA listings, confirming it meets recognized safety standards for electrical installations. The gray PVC construction handles working temperatures from -20 degrees C to 80 degrees C in dry conditions, 60 degrees C in wet conditions, and 70 degrees C in oil-exposed environments, making it suitable for a wide range of service conditions encountered in the field.

This conduit is commonly specified for air conditioning hook-up whips, outdoor equipment connections, and other applications where a flexible, liquidtight raceway is required. Electricians use it in residential and light commercial settings where the raceway must resist moisture intrusion, UV exposure, and incidental chemical contact. The gray color is the standard machine tool gray finish; black and other colors are available from the manufacturer upon request for job-specific requirements.

Key Features

• UL and CSA listed for recognized safety compliance in electrical installations
• Type NM nonmetallic liquidtight construction resists moisture, abrasion, mild acids, alkaline, and oils
• PVC material provides UV resistance for outdoor and exposed-location use
• Wide temperature range: -20 degrees C to 80 degrees C dry, 60 degrees C wet, 70 degrees C oil
• Inside bend radius of 6.5 inches supports clean routing in tight spaces without kinking
• Supplied in a 100-foot coil at 1-inch trade size for standard AC and equipment whip work

Compatibility

Designed as a general-purpose liquidtight nonmetallic conduit for use with standard 1-inch liquidtight fittings in residential and light commercial electrical raceway systems, including air conditioning equipment hook-ups and outdoor wiring applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits before connecting or terminating the conduit at any enclosure or equipment. Use listed liquidtight fittings rated for Type NM conduit to ensure a proper liquidtight seal at termination points. Avoid over-bending below the minimum inside bend radius to prevent restricting wire pull and compromising the conduit wall.

Technical Specifications

• Type: NM (Nonmetallic Liquidtight)
• Material: PVC
• Color: Gray
• Trade Size: 1 inch
• Length: 100 feet
• Inside Diameter Minimum: 1.041 inches
• Inside Diameter Maximum: 1.066 inches
• Outside Diameter Minimum: 1.290 inches
• Outside Diameter Maximum: 1.315 inches
• Inside Bend Radius: 6.5 inches
• Working Temperature (Dry): -20 degrees C to 80 degrees C
• Working Temperature (Wet): 60 degrees C
• Working Temperature (Oil): 70 degrees C
• Weight: 25 pounds per 100 feet
• Country of Origin: United States

Standard Information

• Brand: E-FLEX
• Manufacturer Part Number: 81032
