E-flex 12802 Liquidtight Flexible Conduit 3/4 in 100 Ft

Product Description

The E-FLEX 12802 is a liquidtight flexible non-metallic conduit (LFNC) in the LT style, supplied in a 100-foot carton. It features a steel core wrapped with a black PVC jacket rated for industrial and outdoor use. The inner diameter ranges from 0.82 to 0.84 inches and the outer diameter from 1.03 to 1.05 inches, with a minimum bending radius of 2.5 inches. The plated finish adds corrosion resistance. This conduit is installed by licensed electricians in commercial, industrial, and outdoor wiring applications where a flexible, moisture-resistant raceway is required.

The E-FLEX 12802 is suited for industrial plant wiring, outdoor equipment connections, and any installation requiring a 3/4-inch trade-size flexible conduit with a non-metallic jacket. The PVC jacket resists acids, oils, vapors, sunlight, and corrosion, making it a dependable choice for harsh environments. It carries JIC approval and is compliant with RoHS and WEEE directives, meeting requirements for industrial electrical installations in both domestic and export applications.

Key Features

• LT-style liquidtight flexible non-metallic conduit with steel core and black PVC jacket
• 3/4-inch trade size with inner diameter 0.82 to 0.84 inches and outer diameter 1.03 to 1.05 inches
• Temperature rated from -20 to 80 degrees C for demanding industrial and outdoor environments
• Minimum bending radius of 2.5 inches for flexible routing around obstructions
• Resistant to acids, oil, vapors, sunlight, and corrosion
• JIC approved; RoHS and WEEE compliant

Compatibility

Designed for use with standard 3/4-inch trade-size liquidtight fittings in industrial and outdoor electrical conduit systems. Confirm fitting compatibility with LT-style non-metallic liquidtight conduit before installation.

Installation Notes

Installation is performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits before cutting or terminating conduit. Use fittings rated for liquidtight flexible non-metallic conduit at the 3/4-inch trade size, and ensure all connectors are properly seated and tightened to maintain the liquidtight integrity of the assembly. Do not exceed the minimum bending radius of 2.5 inches, as sharp bends can compromise the jacket and core.

Technical Specifications

• Trade Size: 3/4 inch
• Inner Diameter: 0.82 to 0.84 inches
• Outer Diameter: 1.03 to 1.05 inches
• Length: 100 feet
• Weight: 33 pounds per 100 feet
• Bending Radius: 2.5 inches (minimum)
• Temperature Rating: -20 to 80 degrees C
• Core Material: Steel
• Jacket Material: PVC
• Jacket Color: Black
• Finish: Plated
• Style: LT
• Application: Industrial, Outdoor
• Resistance: Acid, Corrosion, Oil, Sunlight, Vapor
• Approvals: JIC
• Compliance: RoHS, WEEE
• Package Type: Carton

Standard Information

• Brand: E-FLEX
• Manufacturer Part Number: 12802
