Dynabrade 48335 7 Degree Offset Die Grinder 0.4 hp (7 Degree Offset) Replaces 52335, 52331

Product Description

The Dynabrade 48335 is a pneumatic, gearless 7-degree offset die grinder rated at 0.4 hp and capable of up to 25,000 rpm. It features a 1/4 in NPT air inlet, rear exhaust, lever throttle, and composite housing with a 7-degree offset handle. The tool consumes about 23 scfm at 90 psi and includes 1/4 in and 6 mm collet inserts for grinding, deburring, polishing, and finishing applications.

• Gearless pneumatic motor, 0.4 hp, up to 25,000 rpm; air consumption 23 scfm at 90 psi
• Includes 1/4 in and 6 mm collet inserts; 1/4 in NPT air inlet, minimum hose size 1/4 in, rear exhaust, lever throttle
• One-piece spindle and Kevlar phenolic vanes with dual-wick lubrication for reduced run-out and extended gear life

Product Highlights

0.4 hp gearless 7° offset die grinder; 25,000 rpm; 1/4 in and 6 mm collets; 1/4 in NPT inlet; rear exhaust; 23 scfm; composite housing; 73 dBA

Product Information

Standard Information

• Brand: DYNABRADE
• Manufacturer Part Number: 48335
• Country of Origin: United States

Technical Specifications

• Brand: Dynabrade
• Manufacturer Part Number: 48335
• Model: 48335
• Tool Type: 7 Degree Offset Die Grinder
• Motor Type: Gearless pneumatic
• Horsepower: 0.4 hp
• Power (W): 298 W
• Maximum Speed (RPM): 25,000 rpm
• Minimum Speed (RPM): 18,000 rpm
• Air Consumption: 23 scfm (at 90 psi)
• Air Pressure (Required): 90 psi
• Air Inlet: 1/4 in NPT (female)
• Minimum Hose Size: 1/4 in
• Collet Capacity: 1/4 in; 6 mm
• Collet Inserts Included: 1/4 in and 6 mm
• Exhaust Location: Rear
• Throttle Style: Lever (safety-lock lever)
• Handle Type: 7 degree offset
• Housing Material: Composite
• Lubrication: Dual-wick lubrication system saturated with gear oil
• Vanes: Kevlar phenolic vanes
• Spindle: One-piece spindle
• Sound Level: 73 dBA
• Dimensions: 7.3 in L x 3.8 in H
• Weight: 1 lb
• Applications: Grinding, deburring, polishing, finishing, shaping
• Certifications: CE certified; EAC certified
• Includes: Bare tool; 1/4 in collet insert; 6 mm collet insert
• Replaces: 52335, 52331
