Dwyer RMC-108-SSV Rate-Master Flowmeter 180-1800 SCFH Air SS Valve

Product Description

The Dwyer RMC-108-SSV Rate-Master series RMC flowmeter is a 10" scale air flow meter with 1/2" female NPT inlet and outlet connections for inline monitoring and measuring of air flow with an accuracy of + or – 2% of full scale. It is made of injection molded polycarbonate for clear viewing. Commonly used for measuring air flow in medical equipment, air samplers and gas analyzers.

• Accuracy of + or – 2% of full scale for precise readings.
• Integral flow guide stabilizes the float throughout the range.
• Stainless steel back bone with welded pipe thread inserts to absorb piping torque during installation.

Product Highlights

The Dwyer Rate-Master flowmeter is designed for inline monitoring and precise air flow measurement in various applications. Features include a polycarbonate body, stainless steel valve, and easy-to-read scales.

Product Information

Standard Information

• Brand: DWYER
• Manufacturer Part Number: RMC-108-SSV
• Country of Origin: United States

Technical Specifications

• Service: Compatible gases and liquids
• Process Connection: 1/2" female NPT
• Pressure Limit: 100 psi (6.9 bar)
• Temperature Limit: 130°F (54°C)
• Accuracy: 2% of full scale
