Dwyer HFL-4-25 1 FNPT In-Line Flow Monitor 2 to 25 GPM

Product Description

The Dwyer HFL-4-25 is a one FNPT in-line flow monitor suitable for liquids and compatible gases. This device measures flow through a floating orifice disk and variable area flow measurement. Flowing media causes a linear movement of the orifice disk, which in turn operates a magnet. The external magnet follower indicates the flow rate on the scale.

• Flow rate indication ranges from 2 to 25 gallons per minute.
• All wetted parts are in a sealed metal casing for maintenance-free use.
• Can be mounted in various orientations.

Product Highlights

The device is suited for diverse applications such as setting pressure relief valves and monitoring lubricating liquids. Its design accommodates high viscosities and varies plumbing needs.

Product Information

Standard Information

• Brand: Dwyer
• MPN: HFL-4-25

Technical Specifications

• Flow Range: 2 to 25 GPM
• Weight: 1.99 lbs
• Shipping Dimensions: 4.15 x 4 x 2.9 inches
• Size: 1 FNPT
