Dwyer AAFS Air Flow Switch 15 Amps Adjustable Air Flow Paddle Switch

Product Description

The Dwyer AAFS is an adjustable air flow paddle switch that supports a range of air flow applications. Capable of monitoring air velocities from two hundred to one thousand eight hundred feet per minute, this switch features a stainless steel vane that ensures long-term durability. The unit is housed in a robust ABS enclosure designed to withstand tough environmental conditions. Ideal for HVAC systems and industrial processes, it is an essential tool for engineers in need of reliable air flow monitoring.

• Adjustable air flow sensitivity from 200 to 1800 FPM
• 15 Amps at 250 VAC with SPDT switching capability
• IP65 enclosure rating for dust and water protection

Product Highlights

Enhance your air flow control with this easy-to-install switch that reliably detects changes in air movement.

Product Information

Standard Information

• Brand: Dwyer Instruments
• Part Number: AAFS

Technical Specifications

• Amperage: 15 Amps
• Voltage: 250 VAC
• Enclosure Material: ABS
• Paddle Material: Stainless Steel
• Switch Type: SPDT
• Enclosure Rating: IP65
• Weight: 1.1 lbs
• Dimensions: 7.8 inches (D) x 5.4 inches (W) x 4.5 inches (H)
