Dwyer A3025 Photohelic Pressure Switch And Gauge 0 To 25 in. w.c.

Product Description

The Dwyer A3025 is a pressure switch and gauge designed to measure pressures in the range of zero to twenty-five inches of water column. It operates on a power supply of one hundred twenty volts alternating current with a frequency of fifty to sixty hertz. This device is suitable for various HVAC applications and includes features that enhance its functionality and reliability.

• Features two form C relays for versatile application.
• Includes a durable polycarbonate plastic housing.
• Easy to read with a clear gauge for pressure monitoring.

Product Highlights

This device is built to provide precise pressure measurements and includes a spring-loaded friction clutch to prevent damage to settings.

Product Information

Standard Information

• Brand: Dwyer
• Part Number: A3025

Technical Specifications

• Pressure Range: 0 to 25 inches of water column
• Power Supply: 120 VAC
• Frequency: 50 to 60 Hz
• Optional Power: 240 VAC and 24 VAC
• Relay Type: 2 form C relays
