Dwyer 616KD-01 Differential Pressure Transmitter 0 to 2 Inches Water Column Output 4-20mA

Product Description

The Dwyer Instruments 616KD-01 Differential Pressure Transmitter is essential for accurately measuring pressure variations within a range of 0 to 2 inches of water column. Equally effective in industrial settings, this device ensures precision in control systems, enhancing operational efficiency.

• Robust stainless steel construction for durability.
• Compact design facilitates ease of installation.
• Features a 4-20mA DC output, compatible with varied control systems.

Product Highlights

The Dwyer 616KD-01 is designed for robustness, featuring wetted materials crafted from stainless steel that withstand harsh environmental conditions. Its precise measurement of pressure differentials is crucial for applications like monitoring filtration systems, HVAC units, and industrial machinery.

Technical Specifications

• Pressure Range:: 0 to 2 inches WC
• Accuracy: +/-2.00% Full Scale
• Electrical Connections: Screw Terminals
• Power Required: 16 to 35VDC
• Process Connection Size: 1/8 in
• Output: 4 to 20mA DC
• Operating Temperature: 0 Degrees to 140 Degrees F
