Dwyer 605-3 Magnehelic Differential Pressure Transmitter 0-3.0 inch WC

Product Description

The Dwyer 605-3 Magnehelic Pressure Transmitter is engineered to provide precise visual monitoring and electronic control of very low differential pressure in HVAC systems and other industrial applications. Manufactured by Dwyer Instruments, this device integrates the time-proven Magnehelic gauge design with advanced transmitter technology, ensuring reliable and accurate pressure management.

• Robust aluminum housing ensures durability and chemical resistance.
• Two-wire, 4-20 mA control signal for easy integration into existing systems.
• Designed for processes involving air, compatible gases, and non-combustible gases.

Product Highlights

This pressure indicating transmitter is calibrated to provide a +/-2% full-scale accuracy and features a diaphragm-actuated sensor for superior sensitivity and lifespan. The compact unit supports both local indication and remote monitoring, enhancing functionality during maintenance or system troubleshooting.

Product Information

Standard Information

• Brand: Dwyer Instruments
• Model: 605-3

Technical Specifications

• Pressure Range: 0 to 3 inches water column
• Output Signal: 4-20 mA DC
• Connection Type: 1/8 inch Female NPT
• Maximum Operating Temperature: 120 Degrees Fahrenheit
• Power Requirements: 10 to 35V DC
• Dimensions: Diameter - 5 inches, Depth - 2.5 inches
