Dwyer 605-0 Magnehelic Series 605 Differential Pressure Indicating Transmitter 0-0.50 WC Range

Product Description

The Dwyer 605-0 Magnehelic Series 605 Differential Pressure Indicating Transmitter is designed to provide precise monitoring and electronic control of low differential pressure. Ideal for HVAC system control applications, this device offers both visual indication and a 4-20 mA control signal.

• 4-20 mA output signal
• Maximum pressure range of 0.50 WC
• Easy installation with terminal strip

Product Highlights

The Dwyer 605-0 Magnehelic Series 605 is commonly used in HVAC systems for building pressure monitoring. It includes a simple terminal strip on the rear for easy connection in any 4-20 mA control loop powered by a 10-35 VDC supply. The analog dial gauge provides a clear visual indication, allowing for routine maintenance checks and system troubleshooting. Its rugged construction ensures durability.

Product Information

Standard Information

• Brand: Dwyer Instruments
• Item Weight: 2.02 lbs

Technical Specifications

• MPN: 605-0
• Output: 4 to 20 mA DC
• Maximum Pressure: 0.5 inches wc
• Minimum Pressure: 0 inches wc
• Overpressure: 10 psi
• Power Required: 10 to 35VDC
• Connection Location: Back, Side
• Process Connection Size: 1/8 in, Female NPT
• Accuracy: +/-2% Full Scale
• Dial Diameter: 5 inches
