Dwyer 2010AV Air Filter Kit 15 Psi 1/8 Inch Npt

Product Description

The DWYER 2010AV is an air filter kit rated for a maximum operating pressure of 15 psi with 2% accuracy. It features a 1/8-inch FNPT female back and side connection on an aluminum body and aluminum case. The 4-inch dial provides a clear reading range from 0 to 15 psi, and the unit is rated to a maximum of 140 degrees F. Each unit ships with a six-point calibration certificate, making it suitable for use in instrumentation, HVAC, and light industrial air-monitoring applications. Licensed HVAC technicians, instrumentation technicians, and mechanical contractors are the typical installers.

The 2010AV is designed for air-service filter and pressure-monitoring applications where a compact, panel- or surface-mounted gauge is required. Its screw-mount type allows straightforward installation in line or on a panel. The 1/8-inch FNPT connection suits common instrument and filter manifold fittings used in residential, commercial, and light industrial settings. The included calibration certificate supports applications requiring documented accuracy verification at commissioning or during scheduled maintenance.

Key Features

• 15 psi maximum operating pressure with 2% full-scale accuracy
• 1/8-inch FNPT female connection, available at back and side locations
• 4-inch aluminum dial face for easy field reading
• Aluminum body and case construction for corrosion resistance in air-service environments
• Ships with a six-point calibration certificate
• CE Approval, PCT Pattern Approval, and RoHS Letter of Compliance

Compatibility

Designed as an OEM-style replacement or direct-install gauge for air filter monitoring systems requiring a 1/8-inch FNPT connection and a 15 psi maximum pressure rating.

Installation Notes

Installation is typically performed by a licensed HVAC or instrumentation technician. Isolate and depressurize the air line before connecting or disconnecting the gauge. Use appropriate thread sealant on NPT fittings and avoid over-tightening, which can damage aluminum threads. Follow applicable mechanical and instrumentation codes for the installation environment.
