Dwyer 2000-00AV Air Filter Kit 15 Psi 1/8 Inch Fnpt

Product Description

The DWYER 2000-00AV is an air filter kit designed for low-pressure air and gas measurement applications. It operates at a maximum pressure of 15 psi and delivers 2% accuracy across its measuring range, starting from 0.0 inches water column up to 15 inches water column. The unit features a 4-inch aluminum dial face with a back and side connection location, a 1/8-inch FNPT threaded connection, and a screw-mount body. A six-point calibration certificate is included, making this unit suitable for installations where documented accuracy is required. HVAC technicians and instrumentation specialists are the primary trades that install and service this type of gauge assembly.

The 2000-00AV is suited for residential and light commercial HVAC systems where differential pressure or low-pressure air monitoring is needed. Typical applications include filter status monitoring, duct pressure measurement, and air handling unit instrumentation. The 1/8-inch FNPT female connection allows straightforward integration into standard instrumentation ports. The aluminum body and case construction keep the unit lightweight at approximately 1.17 pounds while maintaining durability in typical mechanical room environments.

Key Features

• 15 psi maximum operating pressure with a range starting at 0.0 inches water column
• 2% accuracy across the full measuring range
• 4-inch aluminum dial face for easy field reading
• 1/8-inch FNPT female connection with back and side entry options
• Screw-mount design for secure panel or bracket installation
• Includes six-point calibration certificate for documented traceability
• CE Approval, PCT Pattern Approval, and RoHS Letter of Compliance

Compatibility

Designed as an OEM-style replacement or direct-install air filter gauge kit for residential and commercial HVAC and instrumentation systems using 1/8-inch FNPT port connections.

Installation Notes

Installation should be performed by a qualified HVAC technician or instrumentation specialist. Shut off and isolate the air or gas supply to the measurement port before making any connections. Apply thread sealant appropriate for the service medium to the 1/8-inch FNPT threads and avoid overtightening, which can crack aluminum fittings. Verify the system pressure does not exceed the 15 psi maximum rated operating pressure before returning the system to service.
