Dwyer 1823-2 Low Differential Pressure Switch 0.5-2.0 inch w.c. Replacement 1823-2

Product Description

The Dwyer Low Differential Pressure Switch model 1823-2 is expertly designed for reliability in various industrial applications. This switch accurately controls and measures pressures ranging from 0.5 to 2.0 inches of water column.

• Direct manufacturer product ensuring quality and performance.
• Offers a switch range of 0.50 to 2.0 inches w.c., suitable for diverse industrial needs.
• Features SPDT switch type for versatile switching solutions.

Product Highlights

Engineered for precision with 2% repeatability, this product is a prime choice for applications demanding high accuracy. Set point adjustment is accessible from either side of the panel it is mounted on, making it user-friendly and adaptable to different setups.

Product Information

Standard Information

• Service: Air and non-combustible, compatible gases.
• Temperature Limits: -30 to 180 degrees Fahrenheit.

Technical Specifications

• Pressure Limits: 10 psig continuous, 25 psig surge.
• Electrical Ratings: 15 A at 120-480 VAC, 60 Hz.
• Mounting Orientation: Diaphragm must be in vertical position.
• Agency Approvals: CE, CSA, FM, UL listed.
