Duravent 810003092 Ss Vent Pipe 3 in X 1 Ft UL1738

Product Description

The DURAVENT 810003092 is a FasNSeal stainless steel vent pipe section constructed from AL29-4C alloy, rated for continuous flue gas service up to 480 degrees F. At 3 inches in diameter and 1 foot in length, this section is used to build or extend Category IV positive-pressure vent systems. The AL29-4C stainless steel construction resists the corrosive condensate produced by high-efficiency gas appliances. UL1738 listing confirms third-party testing for venting of gas-fired equipment. Licensed HVAC technicians and mechanical contractors install this pipe as part of a listed FasNSeal venting assembly.

This vent pipe section is suited for residential and light commercial applications where a high-efficiency condensing furnace, boiler, or water heater requires a Category IV positive-pressure vent. The 3-inch diameter fits common appliance collar sizes found on mid-range and higher-output condensing gas equipment. The 1-foot length allows precise layout in tight mechanical rooms or when completing a run that needs only a short extension to reach the vent termination.

Key Features

• AL29-4C stainless steel construction resists acidic condensate corrosion in Category IV vent systems
• Maximum operating temperature of 480 degrees F suitable for positive-pressure flue gas service
• UL1738 listed for venting of gas-fired equipment
• 3-inch diameter x 1-foot length for precise vent run layout
• Part of the FasNSeal venting system for consistent joint integrity throughout the assembly

Compatibility

Designed for use within the FasNSeal Category IV positive-pressure stainless steel venting system. Intended for venting high-efficiency condensing gas furnaces, boilers, and water heaters requiring a UL1738-listed AL29-4C vent assembly in 3-inch diameter configurations.

Installation Notes

Installation must be performed by a licensed HVAC technician or mechanical contractor in accordance with the appliance manufacturer instructions, the FasNSeal system installation guide, and applicable local mechanical codes. Shut off and lock out the appliance before disturbing any portion of an existing vent system. All joints in a Category IV positive-pressure system must be sealed per the listed system requirements to prevent flue gas leakage. Do not mix FasNSeal components with vent pipe or fittings from other manufacturers unless explicitly permitted by the listing.

Technical Specifications

• Pipe Diameter: 3 inches
• Pipe Length: 1 foot
• Pipe Material: AL29-4C Stainless Steel
• Maximum Temperature Rating: 480 degrees F
• Listing: UL1738
• Item Weight: 5.60 pounds

Standard Information

• Brand: DURAVENT
• Manufacturer Part Number: 810003092
