Dura Plastic 413-007 Pvc 90 Degree Elbow 3/4 in Sch 40

Product Description

The DURA PLASTIC 413-007 is a standard 90-degree elbow fitting manufactured from Schedule 40 PVC. It accepts a 3/4-inch socket connection on both ends, allowing a full right-angle direction change in a pressure-rated piping system. This fitting is domestically produced and built to SCH 40/STD wall thickness, making it suitable for cold and ambient-temperature water lines, irrigation systems, and general-purpose plumbing. Licensed plumbers, irrigation contractors, and pool service technicians routinely use this fitting when routing PVC pipe around obstructions or transitioning runs between directions.

This elbow is appropriate for residential and light commercial applications where a 90-degree change of direction is needed in a 3/4-inch PVC line. Common install scenarios include potable water supply, pool and spa plumbing, irrigation laterals, and low-pressure drain or vent configurations. The socket-style ends are solvent-welded to mating pipe or fittings using standard PVC cement and primer per applicable code.

Key Features

• 90-degree elbow geometry for full right-angle direction changes in 3/4-inch PVC runs
• Socket connections on both ends for solvent-weld assembly
• Schedule 40 / STD wall thickness for pressure-rated service
• PVC construction provides corrosion resistance and compatibility with most water-based media
• Domestic manufacture

Compatibility

Designed as an OEM-style replacement or new-installation fitting compatible with standard Schedule 40 PVC piping systems using 3/4-inch socket connections.

Installation Notes

Installation is performed by a licensed plumber or qualified pipefitter. Shut off and depressurize the line before cutting into any existing system. Clean and dry both the pipe end and fitting socket before applying PVC primer and solvent cement; follow the cement manufacturer's cure time before restoring pressure. Installations must comply with applicable local plumbing codes and ASTM D2466 standards for Schedule 40 PVC fittings.

Technical Specifications

• Pipe Size: 3/4 inches
• Connection Type: Socket (both ends)
• Fitting Angle: 90 degrees
• Schedule: SCH 40 / STD
• Material: PVC
• Country of Origin: Domestic

Standard Information

• Brand: DURA PLASTIC
• Manufacturer Part Number: 413-007
