Buy a system bundle and save up to 10%!SHOP ALL BUNDLES WITH THIS PRODUCT INCLUDED
High quality condenser coil with copper tubing and enhanced louvered fin for maximum heat transfer capacity
Top discharge directs hot air and sound away from living area and shrubbery
All units are factory tested
Easy access to electrical panel, pre-wired for easy hook-up
Bi-directional liquid line filter drier factory installed
Width: 28-1/4 in
Refrigerant Type: R-410A
Voltage Rating: 208 to 230 V ac
Horsepower Rating: 1/6 HP
Height: 37 in
Heating Capacity: 18000 BTU
Line Size: 3/8 in
Number Of Phases: 1
Suction Line Size: 3/4 in
Nominal Capacity: 1.5 ton
Compressor Type: Scroll
Specifications Met: c
Lus Intertek Listed, AHRI Certified
Current Rating: 12.2 amp
Sound Level: 74 db(A)
Cooling Capacity: 18000 BTU
Frequency Rating: 60 Hz
Length: 28-1/4 in
Cooling Capacity In Tons: 1.5 ton
Weight: 175 lb.
What Our Customers Are Saying
Thank you for having all these small crazy little parts! I can only imagine the organization of all of this! You are appreciated!
Love this website, prompt call back and had the necessary information that I was inquiring about. And had the part as well.
I found exactly what I needed to replace the compressor of my home HVAC unit, thank you for your service and I will definitely do business with your company again.
So far so good! Customer service great and site is very well laid out and easy to use. So far every part I've needed has been i stock. Thanks Voomi.
Glad I found your website. Saved a bunch of money on this order and will use again in future for my HVAC business.
By purchasing this item, you are agreeing to have this product installed by a trained technician. The installer or servicer assumes all responsibility for injury or property damage that may result. Refer to your local jurisdiction for installer licencing requirements.
